LG 42PJ350 Owner's Manual

MY MEDIA
MY MEDIA
92
MOVIE LIST
Precautions when playing the video files
►Some user-created subtitles may not work properly.
►Some special characters are not supported in subtitles.
►HTML tags are not supported in subtitles.
►Time information in an external subtitle file should be arranged in ascending order to be played.
►The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the
audio language is changed.
►A damaged video file may not be played correctly, or some functions may not be usable.
►Video files produced with some encoders may no
t be played correctly
.
►If the video and audio structure of recorded file is not interleaved, the file not playback properly.
►Video with resolution higher than maximum resolution supported for each frame, cannot be guar-
anteed for smoo
th playback.
►Movie files other than the specified types and formats may not work properly.
►The movie file encoded by the GMC (Global Motion Compensation) is not support
ed.
►Only the files saved in ASCII Code is supported in subtitles.
►Only 250 Korean characters, 500 letters and 500 numbers are supported
for each line of the
subtitle.
►Only 10,000 sync blocks are supported within the subtitle file.
►We do not guarantee smooth playback of profiles encoded level 4.1 or higher in H.264.
►DTS Audio codec is not supported.
►A video file more than 30GB in file size is not supported for playback.
►Playing a video via a USB connection that doesn’t support high speed may not work properly.
►USB storage devices below USB 2.0 are supported as well. But they may not work properly in the
movie lis
t.
►The
video file and its subtitle file must be located in the same folder.
At this time, a video
file name and its subtitle file name must be identical for it to be displayed.
►When you are watching a movie via the Movie List function, you can adjust the picture with the
ENERGY SAVING and
AV MODE button on the remote control. User setup for each picture mode
is not supported.
The movie list is activated once a USB drive is detected. It is used when playing movie files on the TV.
It displays all of the video files it recognizes.
The On-Screen Display on your model may be slightly different.
Supported movie file
ꔛ
Resolution: under 1920 pixel (width) x 1080 pixel (height)
ꔛ
Frame Rate: under 30 frame/sec (1920x1080), under 60 frame/sec (1280x720)
ꔛ
Max bitrate of playable movie file: 20 Mbps (Mega bit per second)
ꔛ
Bit rate of audio format: within 32 kbps to 320 kbps (MP3)
ꔛ
Supported subtitle format: *.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *ssa, *txt
(TMPlayer), *.psb (PowerDivX)

LG 42PJ350 Specifications

General

Audio system	Mono/Stereo/Dual (MTS/SAP)
RMS rated power	20 W
Number of speakers	2
Product color	Black
LED indicators	Stand-by
Panel mounting interface	400 x 400 mm
Integrated clock	Yes
Power requirements	100V - 240V, 50/60 Hz
Mean time between failures (MTBF)	100000 h
HDMI ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical out	1
HD type	XGA
Display diagonal	42 \
Display brightness	1500 cd/m²
Display resolution	1024 x 768 pixels
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	3000000:1
Power consumption (standby)	0.1 W

Weight and Dimensions

Depth (with stand)	260 mm
Width (with stand)	988 mm
Height (with stand)	688.5 mm
Weight (with stand)	21000 g
Depth (without stand)	55.3 mm
Height (without stand)	621.8 mm
Weight (without stand)	20000 g
