LG 65UB930T User Manual

ENGENGLISH
33
MAKING CONNECTIONS
IN
COMPONENT AV
VIDEO AUDIO Y P
B
P
R
VIDEO
AUDIO
L R
Component Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external
device and the TV with a component cable as shown in the following illustration.

If cables are installed incorrectly, it could cause the image to display in black and white or with
distorted color.

Check to ensure the cables are matched with the corresponding color connection.
NOTE
GREEN
BLUE RED
RED
WHITE
GREEN
YELLOW
YELLOW
WHITE
RED
GREEN
BLUE
RED
WHITE
RED
GREEN
BLUE
RED
(Use the composite video cable provided.) (Use the component video cable provided.)
DVD / Blu-Ray / HD Cable Box
(*Not Provided)(*Not Provided)
