MAKING CONNECTIONS
Composite Connection
Transmits analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown in the following illustration.
If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of
the TV.
Check to ensure the cables are matched with the corresponding color connection.
NOTE
IN
COMPONENT
AV
VIDEO AUDIO
Y
P
B
P
R
VIDEO
MONO
( )
AUDIOLR
RED
WHITE
YELLOW
WHITE
RED
WHITE
RED
YELLOW
YELLOW
YELLOW
(Use the composite video cable provided.)
DVD / Blu-Ray / HD Cable Box / VCR
(*Not Provided)
To Next Page
