LG AN-WL100W User Manual

22
APPENDIX
APPENDIX
MODELS
Wireless Media Box
(AN-WL100W)
Dimensions
(Width x Height x Depth)
326.0 mm x 42.8 mm x 226.0 mm
(12.8 inch x 1.7 inch x 8.9 inch)
Weight 1.5 kg (3.3 lb)
Power requirement
DC 12 V 1.1 A
Adapter
In : AC 100-240 V~ 50 / 60 Hz
Out : DC 12 V 2.5A
(Adapter model No. : PA-1031-1 ( LITE-ON) , EADP-30PB B (DELTA) )
MODELS Wireless Ready Dongle
Dimensions
(Width x Height x Depth)
148.0 mm x 23.0 mm x 78.0 mm
(5.8 inch x 0.9 inch x 3.1 inch)
Weight 0.2 kg (0.4 lb)
Environment condition
Operating
Temperature
Operating Humidity
0 °C to 40 °C (32 °F to 104 °F)
Less than 80 %
Storage Temperature
Storage Humidity
-20 °C to 60 °C (-4 °F to 140 °F)
Less than 85 %
■ The specifications shown above may be changed without prior notice for quality improvement.
PRODUCT SPECIFICATIONS
TROUBLESHOOTING
The video function does not work.
No picture & No sound
■ Check whether the TV and the Wireless Media Box are turned on.
■ Is the power cord inserted correctly into the adapter?
■ Is the adapter plug inserted correctly into the Wireless Media Box?
No or poor color
or poor picture
■ Adjust Color in menu option.
■ Are the video cables installed properly?
■ Activate any function to restore the brightness of the picture.
Horizontal/vertical bars
or picture shaking
■ Check for local interference such as an electrical appliance or power tool.
No picture
when connecting
HDMI
■ Check that your HDMI cable is High Speed HDMI Cable.
If the HDMI cables are not High Speed HDMI Cable, flickering or no screen display
can result. Please use the High Speed HDMI Cable.

LG AN-WL100W Specifications

General

Compatibility	LG LX9500, LEX9, LE8500, LE7500, LX6500, LE5500, LE5400, LD650, LD550, PK950, PK750
Product color	Black
Number of products included	1 pc(s)
Package dimensions (W x D x H)	14.8 x 3.9 x 10.9 \

Weight and Dimensions

Weight	2926 g
