ELECTRICAL TROUBLESHOOTING GUIDE

3. TRAY OPERATING IS ABNORMAL

Tray operating is abnormal

Tray open doesn’t work.

Check the loading motor

and front loading mechanism.

Is there tray

control signal input?

(LIC201 Pin41)

Is there Tray

control signal output?

(LIC501 Pin55)

YES

Is there tray

drive voltage output?

(LIC201 Pin27,28)

NO NO

• Check the serial flash operation.

• Check the SATA communication between

B/end MPEG Chip.

• Go to reset or power check.

Check the connection from

LIC501 Pin55. to LIC201 Pin4.

Check the LIC201

YES

Is there tray

drive voltage output?

(Loading Motor)

Check the connector LPF301

and FFC cable connection.

YES
