LG CM4330 User Manual

SPECIFICATIONS
1-11
• GENERAL
Power requirements Refer to the main label.
Power consumption Refer to the main label.
Dimensions (W x H x D) 202 x 307 x 315 mm
Net Weight (Approx.) 3.15 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply DC 5 V 500 mA
• INPUTS
AUX IN 2.0 Vrms (1 kHz, 0 dB), 75 Ω, RCA jack (L, R) x 1
• TUNER
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
AM Tuning Range 522 to 1 620 kHz, 520 to 1 710 kHz or 522 to 1 710 kHz
• AMPLIFIER
Stereo mode 90 W + 90 W (4 Ω at 1 kHz, THD 10 %)
Surround mode (Front) 90 W + 90 W (4 Ω at 1 kHz, THD 10 %)
• CD
Frequency Response 100 to 20 000 Hz
Signal-to-noise ratio 75 dB
Dynamic range 80 dB
• FRONT SPEAKER
Model CMS4330F
Type 2 Way 2 Speaker
Impedance 4 Ω
Rated Input Power 90 W
Max. Input power 180 W
Net Dimensions (W x H x D) 204 x 235 x 301 mm
Net Weight 2.48 kg
 Design and specifications are subject to change without notice.

LG CM4330 Specifications

General

Karaoke	No
Bass reflex	Yes
Speaker type	4-way
RMS rated power	180 W
Number of speakers	2
Type	Home audio mini system
Product color	Black
Disc types supported	CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	MP3, WMA
Supported radio bands	AM, FM
Display type	-
Apple docking compatibility	Not supported
USB 2.0 ports quantity	1
Power source	AC
Volume control	Rotary
