5. PWM MODULATION CHECK
PWM MODULATION PART CHECK
Check
CN105 Pin11 3.7 VA.
• Check IC601(TAS5548)
VDD 3.3 V
• Check VDD Core 1.2 V.
NO
Refer to
SMPS troubleshooting.
Check
X602(19.2 MHz)
operation.
NO
Replace X602(19.2 MHz).
Check X602
(19.2 MHz).
OK
YES
NO
Check
IC601 Pin21 input.
Check IC101
(LC87FC096AVU)
Pin41:PWM RESET
Pin45:PWM SDA
Pin46:PWM SCL
output.
NO
Replace R660,R659,R658.
Check line
resistor output
RST: R660 / SCL: R659 /
SDA: R658.
NO
YES
YES
YES
YES
YES
YES
OK
YES
A
3-22
AUDIO ELECTRICAL TROUBLESHOOTIHG GUIDE
