PROGRAMMING MODE - TEST MODE
PROGRAMMING MODE -
TEST MODE
Diagnostic tests: (display)
This program has been added for testing the washer and detecting errors.
1.
According to pressing START button, test move to the next step.
Entering the test mode
Data Name
Button Display Description
Entering
the test mode
1. Entering programming mode Insert service card (card type), turn on/off toggle switch (Coin type).
2. 90°C MEDICAL
Press the 90°C MEDICAL button. Then appears in the
display.
3. START Enter the diagnostic test mode.
Number of times the
START button is pressed
Check Point Display
None
1time
Turns on all lamps and locks the door Displayed 1U XX, 1g XX and 1O XX alternately (Version)
2 times
Tumble Clockwise. rpm (42~50)
3 times
Low Speed Spin rpm (550~650)
4 times
High Speed Spin rpm (1000~1150)
5 times
Inlet valve for main water turns on. Water level frequency (26.2~23.0 kHz)
6 times
Inlet valve for hot water turns on. Water level frequency (26.2~23.0 kHz)
7 times
Inlet valve for softener turns on. Water level frequency (26.2~23.0 kHz)
8 times
Inlet valve for bleach turns on. Water level frequency (26.2~23.0 kHz)
9 times
Tumble counter clockwise. rpm (42~50)
10 times
Turn on the heater Displayed XX
11 times
Drain Pump turns on. Water level frequency (26.2~23. 0 kHz)
12 times
Turns on all lamps. Displayed 1U XX, 1g XX and 1O XX alternately
13 times
Button Checks. Displayed 1U XX, 1g XX and 1O XX alternately
14 times
High Speed Spin rpm (1000~1150)
15 times
PDA Signal Check this function is not applied in this machine
16 times
NOTE
• Make sure the drum is empty when a diagnostic test is performed. Do not use .
