Installing Hole cap
1
Take the hole cap out from manual bag.
2
Insert the hole cap (5 pieces) into hose
connect in back of the machine.
Foam Tub Support Carton Base
NOTE
• Save the bolt assemblies for future use.
To prevent damage to internal
components, DO NOT transport the
washer without reinstalling the shipping
bolts.
• Failure to remove shipping bolts and
retainers may cause severe vibration
and noise, which can lead to permanent
damage to the washer. The cord is
secured to the back of the washer with
a shipping bolt to help prevent operation
with shipping bolts in place.
NOTE
• In case of using auto dosing feature,
inserting hole cap is unnecessary.
1
Remove the bottom two shipping bolts
with the wrench (included) to fully loosen
all four shipping bolts by turning them
counterclockwise and then pulling them out.
2
Locate the four hole caps included in the
accessory pack and install them in the
shipping bolt holes.
Unpacking and removing
shipping bolts
When removing the washer from the carton
base, be sure to remove the foam drum
support in the middle of the carton base.
If you must lay the washer down to remove the
base packaging materials, always lay it carefully
on its side.
DO NOT lay the washer on its front or back.
Shipping
bolt
Retainer
Cap
Hole cap
To Next Page
