Connecting the drain line
Secure the drain hose in place to prevent
moving and leaking.
Installation of drain hose
NOTE
• The drain hose should be properly secured.
Failure to properly secure the drain hose
can result in flooding and malfunction.
• While installing drain hose, height of hose
should not be over 2.7 inch (from bottom
of the machine).
• The drain must be installed in accordance
with any applicable local codes and
regulations.
• Make sure that the water lines are not
stretched, pinched, crushed, or kinked.
1
Remove drain cap from the machine.
2
Place the end of the drain hose in the
drainage ditch of the floor drain system.
The drain hose should not be placed higher
than 2.7 in. from the bottom of the washer.
• Make sure that the hose is not twisted.
• Do not submerge the end of the hose.
Max. 2.7
"
(6.9 cm)
