LG GX / SPN5-W User Manual

1-14
Copyright © 2020 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
SPECIFICATIONS
• GENERAL
Power consumption Refer to the main label on the unit.
AC adapter Model : DA-50F25
Manufacturer : Asian Power Devices Inc.
Input : 100 - 240 V ~ 50 - 60 Hz
Output : 25 V 2 A
Dimensions (W x H x D) Approx. 1446 mm x 150 mm x 32.5 mm
(56.9 inch x 5.9 inch x 1.28 inch)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Bus Power Supply (USB) 5 V 500 mA
Available Digital Input Audio
Sampling Frequency
32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Available Digital Input Audio format PCM/ Dolby Atmos / Dolby Digital / Dolby TrueHD/ DTS X Input
• INPUT/OUTPUT
OPTICAL IN (Digital audio in) 3 V (p-p), Optical jack x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
• AMPLIFIER (RMS Output)
Total 420 W RMS
Front 80 W (40 W + 40 W) RMS x 2 (4 Ω at 1 kHz, THD 10 %)
Center 40 W RMS (4 Ω at 1 kHz, THD 10 %)
Subwoofer 220 W RMS (3 Ω at 1 kHz, THD 10 %)
• WIRELESS SUBWOOFER
Power requirements Refer to the main label on the wireless subwoofer.
Power consumption Refer to the main label on the wireless subwoofer.
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 220 W RMS
Max. Input Power 440 W RMS
Dimensions (W x H x D) Approx. 180 mm x 394 mm x 290 mm
(7.1 inch x 15.6 inch x 11.5 inch)
SPK8-S (SPK8-S, S78S1-S), Sold Separately
• WIRELESS RECEIVER
Power requirements Refer to the main label on the wireless receiver.
Power consumption Refer to the main label on the wireless receiver.
Rear 70 W RMS x 2 (3 Ω at 1 kHz, THD 10 %)
Dimensions (W x H x D) Approx. 60 mm x 220 mm x 175 mm
(2.4 inch x 8.7 inch x 6.9 inch)
• REAR SPEAKERS (Each)
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 70 W RMS
Max. Input Power 140 W RMS
Dimensions (W x H x D) Approx. 100.0 mm x 140.0 mm x 100.0 mm
(3.9 inch x 5.5 inch x 3.9 inch)
• Designs and specifications are subject to change without prior notice.
