2. CAPACITOR VOLTAGE
3. CONNECTOR VOLTAGE
3-223-21
Designator Description SPEC. Real Value (#1, #2)/ V Temperature Spec.
C703, C734, C738, C769,
C790, C799, C668
Capacitor, AL,Chip 330 uF/ 35 V 25.30 25.40 25.40 25.50 25.40 -55~105 °C/ 5000 HR
CA678 Capacitor, AL,Chip 10 uF/ 35 V 25.30 25.40 25.40 25.50 25.40 -40~105 °C/ 1000 HR
CA679 Capacitor, AL,Chip 100 uF/ 16 V 3.30 3.30 3.40 3.30 3.40 -55~105 °C/ 2000 HR
CA680, CA681 Capacitor, AL,Chip 47 uF/ 16 V 3.30 3.30 3.40 3.30 3.40 -55~105 °C/ 2000 HR
CN105 / CN601 (MAIN <-> AMP)
POWER MAIN (CN105) AMP (CN601) SPEC.
12 VA 12.08 V 12.07 V 12 V(11.5~12.5 V)
3.3 VA 3.36 V 3.33 V 3.3 V(3.15~3.45 V)
CN203 / CNF02 (MAIN <-> FRONT)
POWER MAIN (CN203) FRONT (CNF02) SPEC.
3.3 VA 3.39 V 3.36 V 3.33 V(3.2~3.4 V)
VCC_5V 5.17 V 5.17 V 5.0 V(4.8~5.2 V)
CN100 (MAIN <-> WIRELESS WOFFER)
POWER MAIN WIRELESS REAR SPEC.
WLS_3V3 3.33 V 3.33 V 3.3 V(3.15~3.45 V)
CN101 (MAIN <-> WIRELESS REAR)
POWER MAIN WIRELESS REAR SPEC.
RBOX_3V3 3.34 V 3.33 V 3.3 V(3.15~3.45 V)
CN202 (MAIN <-> BT Module)
POWER MAIN BT Module SPEC.
3.3 VA 3.36 V 3.35 V 3.3 VA(3.0~3.6 V)
CN204 / CNK01 (MAIN <-> USB)
POWER MAIN USB SPEC.
USB_5V 5.19 V 5.19 V 5.0 V(4.75~5.25 V)
