5-3
Copyright © 2020 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
PWM IC
Wireless
TX
Wireless
RX
RL
LPF
AMP
RR
LPF
AMP_PDN
RL+,-/RR+,-
AMP_SD
I2S I2C
R
PAIRING
LED (RED, GREEN)
BLOCK DIAGRAM
