6
INSTALLATION INSTRUCTIONS
Make sure the house water supply is turned off
before connecting the dishwasher water lines.
1. This dishwasher must be connected to a hot
water supply between 120°F (49°C) and 149°F
(65°C). This temperature range provides the
best washing results and shortest cycle time.
To prevent damage to dishes, temperature
should not exceed 149°F (65°C).
2. When connecting the dishwasher water line,
sealing tape or compound should be used on
pipe threads to avoid leaks. Tape or compound
should not be used on compression fittings.
3. Shut off the water supply prior to connecting
the dishwasher water line.
4. The water supply tube must be located in the
left side channel as shown in the figure.
STEP 3: PREPARE THE WATER SUPPLY CONNECTION
STEP 4: PREPARE THE DISHWASHER
wWARNING
Don’t pull or lift with the handle; doing so can
damage the door and hinges. Open door and
grab body frame and top front opening of tub.
FIG. 7
FIG. 8
