LG OM7560 Owner's Manual

Getting Started14
Getting Started
1
Front panel / Rear panel
a DANCE LIGHTING (Lighting ball)
- Shows the various lighting patterns and color.
- You can control angle up and down with your
finger.
b Disc tray
c MIC 1 / 2 jack
d PORT. IN
e
Remote sensor
f ANTENNA (FM)
g AUX IN / OUT
h AC in socket
y Connect the power cord to wall outlet
directly if possible. Or when you use an
extension cable, it is highly recommended
to use an extension cable of 110 V / 15 A
or 230 V / 15 A, otherwise the unit may
not operate properly because of the lack of
power supply.
y Do not overload the extension cord with
excessive electrical load.
>
Caution
OUT IN
a
f
g
h
b
c
d
e
OUT IN
a
f
g
h
b
c
d
e

LG OM7560 Specifications

Power

power consumption networked standby	0.5 W
bus power supply (USB)	5 V 0 500 mA
amplifier output power	1, 000 W

Wireless Specifications

frequency range	2402 to 2480 MHz
output power	10 dBm
minimum distance from body	20 cm

Weight and Dimensions

dimensions	330 mm x 815 mm x 302 mm
net weight	16.8 kg
