Appendix 57
Appendix
6
Specifications
General (LAS655K)
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 1.5 W (If all network ports are activated.)
Dimensions (W x H x D) Approx. 1066 mm x 76 mm x 53 mm
Net Weight (Approx.) 3.3 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
Inputs/Outputs
HDMI OUT (Video/Audio) 19 pin (Type A, HDMI™ Connector) x 1
DIGITAL OPTICAL IN (Audio) 3 V (p-p), Optical jack x 1
Amplier
Total 320 W
Front 80 W x 2 (4 Ω at 1 kHz)
Subwoofer 160 W (3 Ω at 70 Hz)
THD 10 %
Wireless subwoofer (S55A1-D)
Power requirements Refer to the main label on the subwoofer.
Power consumption Refer to the main label on the subwoofer.
Type 1 Way 1 speaker
Impedance 3 Ω
Rated input power 160 W
Max. input power 320 W
Dimensions (WxHxD) 171 mm x 390 mm x 261 mm
Net Weight 5.6 kg
System
Signal system Standard PAL/NTSC color TV system
LAN port Ethernet jack x 1, 10BASE-T / 100BASE-TX
Wireless LAN (internal antenna) IEEE 802.11b/g/n (2.4 GHz band)
Bus Power Supply (USB) 5 V
0
500 mA
y
Design and specications are subject to change without notice.
