SPIN TROUBLE
Check the
S.PRESSURE SWITCH
ASSEMBLY
or HOSE (Pressure).
If the problem is on the
S.PRESSURE SWITCH
ASSEMBLY or the HOSE,
replace the S.PRESSURE
SWITCH ASSEMBLY or the
HOSE.
Normal
Correct the connector.
Replace the STATOR
ASSEMBLY
(4417FA1994E)
Check on the spinning, is the frequency of the
water level 248 or more. The frequency can be
checked by pressing the Rinse and Spin buttons at
the same time on the program.
When pressing Rinse, Spin and POWER buttons at
the same time after power off, press the Start/Pause
button 2 times, is the drum spinning at low speed?
Is it disconnected, or disassembled?
[Red:3pin (1), NA:4pin (2)]
Check the motor connector, Is the resistance of
the terminal same as the figure?
MOTOR TERMINAL (1)
Resistance of terminal:
About 5 10
Replace the MAIN PWB ASSEMBLY
To Next Page
