LG WM2277HW Service Manual

27
Softener
cap
Liquid detergent cap
SOFTENER
MAX
SOFTENER
MAX
Hot water
Prewash
Bleach
Main wash
Bleach cap
SOFTENER
ABNORMAL SOUND
LIQUID DETERGENT/SOFTENER/BLEACH DOES NOT FLOW IN
Secure the bolt.
Replace the STATOR
ASSEMBLY or ROTOR
ASSEMBLY.
Refer to
NO WATER SUPPLY
Check the wiring on the
dispenser.
Put it in the correct
compartment.
Clean the Cap and
Container.
Is the motor bolt loosened?
Is there friction noise coming from the motor?
Is water supplied?
Are the plugs correctly connected to the terminals of
the INLET VALVE ASSEMBLY?
Is liquid detergent/softener/bleach put in the correct
compartment of the drawer?
Is the liquid detergent/softener/bleach cap clogged?

LG WM2277HW Specifications

General

Type	Front Load Washer
Energy Star	Yes
Color	White
Height	39 inches
Steam Washer	Yes
Voltage	120 V
Spin Speed	1200 RPM
