LG WM2277HW Service Manual

3
1. SPECIFICATIONS
ITEM WM2677H*M WM2277H*/WD-11270BD WM2177H* WM2077CW
COLOR W: BLUE WHITE, B: BLACK PEARL, S: TITANIUM
POWER SUPPLY AC 120 V, 60 Hz
PRODUCT WEIGHT 190 lbs. (86 kg)
WASHING 280 W
DRAIN MOTOR 80 W
WASH HEATER 1000 W –
WASH 42 rpm
SPIN
0-1320 rpm 0-1100 rpm 0-1000 rpm
CYCLES 9 7
WASH/RINSE TEMPERATURES 5
SPIN SPEEDS 5
OPTIONS Prewash, Stain Cycle, Quick Cycle, Extra Rinse, Rinse+Spin, Delay Wash
CUSTOM PROGRAM Incorporated
WATER CIRCULATION Incorporated –
OPERATIONAL WATER PRESSURE 4.5
-
145 psi (30-1000 kPa)
CONTROL TYPE Electronic
WASH CAPACITY [cu. ft.] 3.32 (3.83 IEC) 3.22 (3.72 IEC)
DIMENSIONS 27” (W) X 29
3
/
4
” (D) X 38
11
/
16
” (H), 50
13
/
16
” (D, door open)
DELAY WASH up to 19 hours up to 12 hours up to 9 hours
DOOR SWITCH TYPE PTC + Solenoid
WATER LEVEL 10 steps (by sensor)
LAUNDRY LOAD SENSING Incorporated
ERROR DIAGNOSIS Incorporated
AUTO POWER OFF Incorporated
CHILD LOCK Incorporated
RLM ENABLE Incorporated –
ELECTRIC POWER
CONSUMTION
REVOLUTION SPEED

LG WM2277HW Specifications

General

Type	Front Load Washer
Energy Star	Yes
Color	White
Height	39 inches
Steam Washer	Yes
Voltage	120 V
Spin Speed	1200 RPM
