LG WM2650HVA User Manual

13
INSTALLATION INSTRUCTIONS
ENGLISH
Unpacking and removing shipping bolts
When removing the washer from the carton base, be sure to
remove the foam drum support in the middle of the carton
base.
If you must lay the washer down to remove the base
packaging materials, always lay it carefully on its side.
Do NOT lay the washer on its front or back.
1
Remove the bottom two shipping bolts with the wrench
(included) to fully loosen all four shipping bolts by turning
them counterclockwise and then pulling them out.
Shipping
bolt
Retainer
2
Locate the four hole caps included in the accessory pack
and install them in the shipping bolt holes.
Cap
NOTE
Save the bolt assemblies for future use. To prevent
y
damage to internal components, DO NOT transport the
washer without reinstalling the shipping bolts.
Failure to remove shipping bolts and retainers may
y
cause severe vibration and noise, which can lead to
permanent damage to the washer. The cord is secured
to the back of the washer with a shipping bolt to help
prevent operation with shipping bolts in place.

LG WM2650HVA Specifications

General

Door hinge	Left
Display type	LED
Loading type	Front-load
Drum material	Stainless steel
Product color	Graphite
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	4-way
Drum capacity	10.1 kg
Delay start (max)	19 h
Spin-drying class	-
Maximum spin speed	1200 RPM
Noise level (wash)	- dB
Load balancing system	No
Number of washing programs	9
Energy consumption washing per cycle	- kWh
Package depth	787 mm
Package height	1066 mm
Package weight	87490 g

Weight and Dimensions

Depth	736 mm
Width	685 mm
Height	965 mm
Weight	82460 g
