14 PRODUCT OVERVIEW
Connecting the Drain Hose
Connect the drain hose to either a standpipe or
laundry tub.
NOTE
• The drain hose should always be properly secured.
Failure to properly secure the drain hose can result
in ooding and property damage.
• The drain must be installed in accordance with any
applicable local codes and regulations.
• Make sure that the drain hose is not stretched,
pinched, crushed, or kinked.
• Do not install the drain hose with the end lower than
29.5 inches (0.7 m) or higher than 96 inches (2.4
m) above the bottom of the washer or more than 60
inches (1.5 m) away from the washer.
• Never create an airtight seal between the hose and
the drain with tape or other means. If no air gap
is present, water can be siphoned out of the tub
resulting in poor wash/rinse performance or clothing
damage.
Option 1: Standpipe
1
Clip the end of the hose into the elbow
bracket.
Connect the elbow bracket within 4 inches (10
cm) of the end of the drain hose. If the drain
hose is extended more than 4 inches (10 cm)
beyond the end of the elbow bracket, mold or
microorganisms could spread to the inside of the
washer.
No more than 4
inches (10 cm)
Elbow bracket
2
Insert the end of the drain hose into the
standpipe.
Drain hose
Elbow bracket
3
Use a tie strap to secure the drain hose in
place.
Option 2: Laundry Tub
1
Clip the end of the hose into the elbow
bracket.
Connect the elbow bracket within 4 inches (10
cm) of the end of the drain hose. If the drain
hose is extended more than 4 inches (10 cm)
beyond the end of the elbow bracket, mold or
microorganisms could spread to the inside of the
washer.
No more than 4
inches (10 cm)
Elbow bracket
2
Hang the end of the drain hose over the side
of the laundry tub.
Drain hose
Elbow bracket
3
Use a tie strap to secure the drain hose in
place.

LG WM3460CW Specifications

General

Style	front load
Color	white
Washer Capacity	4.5 cubic feet
Max Spin Speed	1300 revolutions per minute
Spin Speeds	3
Number of Cycles	10
Cycle Selections	normal, perm. press, heavy duty, delicates, towels, speed wash, bedding, tub clean, whites, downloaded
Options	fresh care, prewash, remote start, delay wash, wi-fi, add garments, coldwash, extra rinse, rinse+spin, child lock, normal, perm. press, heavy duty, delicates, towels, speed wash, bedding, tub clean, whites, downloaded
Noise level	lodecibel quiet operation
Temperature Settings	3
Temperature Selections	hot, warm, cold
Soil Levels	heavy, normal, light
Internal Heater	yes
Control Panel	dial, touchpad
Delay Start / End	yes
Child Lock	yes
Cycle Signal	yes
Steam	no
Dispenser	single load
Smart Home	remote operation, cycle downloads, service notifications, smartdiagnosis, energy monitoring, true
Wi-Fi	wi-fi
Annual Energy Consumption	100 kilowatt hours
Voltage	120 volts
Current	10 amperes

Weight and Dimensions

Depth	30 1/4 inches
Height	39 inches
Width	27 inches
Net Weight	187 pounds
