LG WT1201C Series User Manual

11
INSTALLATION INSTRUCTIONS
ENGLISH
INSTALLATION INSTRUCTIONS
Installation Overview
(1) (2) (3)
(4)
(7)
(5) (6)
Hot
Cold
WARNING
y
Washer is heavy! Two or more people are required when moving and unpacking the washer.
Failure to do so can result in
back or other injury.
y
Store and install the washer where it will not be exposed to temperatures below freezing or exposed to outdoor weather
conditions.
Failure to follow this warning can cause serious injury, fire, electric shock, or death.
y
Properly ground washer to conform with all governing codes and ordinances.
Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
y
To reduce the risk of electric shock, do not install the washer in humid spaces.
Failure to follow this warning can cause
serious injury, fire, electric shock, or death.
y
The base opening must not be obstructed by carpeting when the washer is installed on a carpeted floor.
y
Do not remove ground prong. Do not use an adapter or extension cord. Plug into a grounded 3-prong outlet.
Failure to
follow this warning can cause serious injury, fire, electric shock, or death.
Checking and choosing the
proper location
Unpacking the washer Connecting the water line
Connecting the drain line
Leveling the washing
machine
Plugging in the power cord
and grounding
Test run

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
