LG WT1201C Series User Manual

12
INSTALLATION INSTRUCTIONS
Checking and choosing the proper
location
Install the washing machine on a solid floor that is strong and
rigid enough to support the weight of the washing machine,
even when fully loaded, without flexing or bouncing. If the
floor has too much flex, you may need to reinforce it to make
it more rigid. If the floor is not solid, it may cause severe
vibration and noise.
1
Clean the floor before installation.
- Make sure to select solid and smooth ground.
2
Two or more people are needed for moving and
unpacking the washing machine.
3
Allow for sufficient space between the walls and the
washing machine for installation.
Space requirements
You must allow sufficient space for water lines, the drain
line, and airflow.
NOTE
y
Be sure to allow for wall, door, or floor moldings that
may increase the required clearances.
Installing on a floor
26.8″
(68.0 cm)
4.7″
(12.0 cm)
54.33″
(138.0 cm)
(with lid
open)
27.4″
(69.6 cm)
0.8″
(2.0 cm)
0.8″
(2.0 cm)
40.16″
(102.0 cm)
NOTE
y
Before installing the washer, make sure the floor is
clean, dry and free of dust, dirt, water and oils so the
washer feet cannot slide easily. Leveling feet that can
move or slide on the floor can contribute to excess
vibration and noise due to poor contact with the floor.

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
