Level Up
™
Installation and Owner’s Manual
(For Aftermarket Application)
Troubleshooting - Touch Pad
LCD Message What's Happening? What Should Be Done?
****ERROR****
Excess Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during auto operation. Relocate the trailer.
****ERROR****
Excessive Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during manual operation. Relocate the trailer.
****ERROR****
Feature Disabled
Front of trailer below level when starting Auto Level process
(only when trying to initiate Hitch Recognition).
Push the “FRONT” button to raise the trailer up to hitch height and
connect to tow vehicle.
Touch pad power not cycled between consecutive leveling
operations.
Turn touch pad off and then back on to reset the system.
Zero point not set. Set zero point.
****ERROR****
Low Voltage
Battery voltage dropped below 9.5V.
Check wiring - repair or replace.
Test battery voltage under load - charge or replace.
****ERROR****
Out Of Stroke
Jack has reached maximum stroke length and is unable to
lift.
Check disposition of jacks and/or relocate the trailer.
****ERROR****
External Sensor
Bad connection or wiring from the controller to the rear
sensor.
Replace or repair connection to rear remote sensor.
****ERROR****
Jack Time Out
Time limit exceeded for the requested auto operation. Check disposition of jacks.
****ERROR****
Auto Level Fail
Unable to auto level due to uneven ground. Check disposition of jacks and/or relocate the trailer.
Unable to auto level due to zero point being set incorrectly. Reset zero point.
****ERROR****
Bad Calibration
Sensor calibration values are out of range. Replace controller.
****ERROR****
Internal Sensor
Internal sensor problem. Replace controller.
**PANIC STOP**
Function Aborted
The user pressed a button on the touch pad during an
automatic operation.
Restart automatic operation and then refrain from pressing any buttons
on the touch pad.
NOTE: To clear an error from the touch pad, repair or
otherwise correct the issue, then press “ENTER”. If the
error is still present, the message will be displayed again.
Error Codes
ENSURE THE TRAILER IS SUPPORTED AT BOTH THE
FRONT AND REAR WITH JACK STANDS BEFORE
PERFORMING ANY TROUBLESHOOTING OR SERVICE
TO THE TRAILER. FAILURE TO DO SO MAY RESULT IN
DEATH OR PERSONAL INJURY.
