GB-32
GB
Using the Features
This feature is not available in all countries.
To insert the Common Access Module
1. Before you insert the Common Access Module,
ensure that the TV is switched off and the viewing
card is inserted in accordance with the Service
Provider’s instructions.
2. Insert the Common Access Module into the slot.
Flip the Common Access Module to another side
and try again if you feel resistance.
3. Switch the TV on.
To remove the Common Access Module
1. Before you remove the Common Access Module,
ensure that the TV is switched off.
2. Pull the Common Access Module from the slot.
3. Switch the TV on.
To view the module information
1. Press the MENU button and then use the buttons to select the DTV
menu and then press the
button.
2. Press the
buttons to select CI.
4. Press the
buttons and then press the OK button to display CI
information (Status / Messages / Language Setup / Update Software / Quit).
5. Press the EXIT button to return back to the previous menu.
6. Press the EXIT button again to exit the menu.
3. Press the OK button or the
button to display the Common Interface screen
and then press the OK button.
CI (Common Interface) (DTV Mode)
The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These
services are provided by TopUp TV (UK only) and others. The Common Access Module and viewing card can be obtained from the
service provider.
Right Rear Side View of TV
CARD FACE FRONT
CI (Common Interface) slot
Allows the Common Access Module to be inserted
and access the content that has been encrypted.
CARD FACE FRONT
Common Access
Module
Do not repeatedly insert or remove the
Common Access Module as this may damage
the interface and cause a malfunction.
This screen is for illustration only.
