Logitech HARMONY 700 User Manual

10
The Harmony 700 senses when you pick it up, and lights up the display and buttons.
To set the length of time the backlight stays on, follow these steps:
From your Harmony Remote Software:
Select the 1. Remote Settings tab.
Click 2. Display Settings.
Next to Glow Timing, select the number of seconds before the backlight turns off 3.
automatically, and click Save.
Setting the backlight timing
Your Harmony 700 comes with an AC adaptor for charging the batteries in
your remote. To charge the batteries, just insert the USB cable into the top
of the remote, plug the other end of the cable into the AC adaptor, and then
plug the AC adaptor into a wall outlet and charge.
Charging your remote
Use only NiMH replacement batteries, size AA R6 with
a minimum of 1800 mA.
Caution: Risk of explosion if battery is replaced by an
incorrect type. Use and replace only with same type and
rating as the battery provided. Charge only with
the power outlet adapter provided with your remote.

Logitech HARMONY 700 Specifications

General

LCD Size	1.5" Diagonal
LCD Resolution	128 x 128
LCD Screen	65, 000 Color
Backlit keypad	Yes
Backlight Color	White
Power Source	Rechargeable
Power Type	NiMH AA
Brands Supported	5, 000+
Devices Supported	200, 000+
Maximum number of devices per account	6
IR Learning	Yes (Up to 200 Khz)
Learning Capabilities	Any IR Device
IR Transmitters	2
IR Transmission Range	Up to 50 ft
Warranty	2 Years
Memory Type	Flash
Memory Amount	2MB
Supported Platforms	Windows 2000/XP/Vista MAC OS X 10.3 +

Weight and Dimensions

Weight	6 oz (with battery installed)
Dimensions	8.75” x 2.3” x 1.3”
