Logitech HARMONY 700 User Manual

27
Option 3 — Select the input from an on-screen
menu
In this case, your device uses an on-screen menu from
which you can select the input you want.
When you press the source button, the menu appears
on your TV screen. Then, you use another button on the
remote to choose the input you want, and then a third
button to select the input.
For example, you press the source button to display the on-screen menu, the arrow keys to select
an input, and then the OK button enter your selection.
Option 4 — Select the source from a list
In this case, your device has a list of inputs and you can use
the buttons on the remote to select the input you want
from the list.
After you press the source button, you have to press
another button on the remote that selects the input you
want.
In this option, there’s no menu from which to choose (Option 3) and you don’t have to cycle through
all inputs to get to the one you want (Option 1).
Step 1— Turn on all your devices
To determine which devices are using which inputs, you should start by turning on all the devices in
your entertainment system.
If possible, you should even start something playing in your DVD player, CD player, VCR, etc.
By having all your devices on, it’s easier to see how they’re connected.
It’s also handy to have some paper and a pen so you can note which devices are connected to
which inputs.

Logitech HARMONY 700 Specifications

General

LCD Size	1.5" Diagonal
LCD Resolution	128 x 128
LCD Screen	65, 000 Color
Backlit keypad	Yes
Backlight Color	White
Power Source	Rechargeable
Power Type	NiMH AA
Brands Supported	5, 000+
Devices Supported	200, 000+
Maximum number of devices per account	6
IR Learning	Yes (Up to 200 Khz)
Learning Capabilities	Any IR Device
IR Transmitters	2
IR Transmission Range	Up to 50 ft
Warranty	2 Years
Memory Type	Flash
Memory Amount	2MB
Supported Platforms	Windows 2000/XP/Vista MAC OS X 10.3 +

Weight and Dimensions

Weight	6 oz (with battery installed)
Dimensions	8.75” x 2.3” x 1.3”
