Lombardini 15 LD 400 User Manual

12
DATE
22.12.2003
COMPILER TECO/ATI
REG. CODE
1-5302-467
MODEL N°
50707
DATE OF ISSUE
06-95
REVISION 05
ENDORSED
IV
15 LD 315
15 LD 350
15 LD 225
15LD 315
1
78
66
315
20,3:1
3600
5,0(6,8)
4,6(6,2)
4,1(5,6)
15@2400
262
0,0035
1,2
12/44
33
480
5000
200
25°
35°
***
15LD 350
1
82
66
349
20,3:1
3600
5,5(7,5)
5,1(7,0)
4,7(6,4)
16,6@2400
260
0,0038
1,2
12/44
33
540
5000
200
25°
35°
***
N.
mm
mm
Cm
3
Nm
g/kW.h
l/h
lt
V/Ah
kg
l./min
l./min
kg.
15LD 225
1
69
60
224
21:1
3600
3,5(4,8)
3,3(4,5)
3,1(4,2)
10,4@2400
267
0,0021
0,9
12/36
28
350
3800
150
25°
35°
***
TIPO MOTORE
Number of cylinders
Bore
Stroke
Swept volume
Compression ratio
R.P.M.
N 80/1269/EEC-ISO 1585
Power kW (HP) NB ISO 3046 - 1 IFN
NA ISO 3046 - 1 ICXN
Max. torque *
Fuel consumption **
Oil consumption
Capacity of standard oil sump
Recommended battery
Dry weight
Combustion air volume at 3600 r.p.m.
Cooling air volume at 3600 r.p.m.
Max.permissible driving shaft axial load in both directions
continuous service for up to 30 min.
Max. inclination discontinuous service for about 1 min.
permanent service
* Referred to N power
** Referred to NB power
*** Depending on the application
CHARACTERISTICS 15 LD 225, 15 LD 315, 15 LD 350
TECHNICAL DATA

Lombardini 15 LD 400 Specifications

General

Brand	Lombardini
Model	15 LD 400
Category	Engine
Language	English
