INTRODUCTION
Backhoe Components
Terms for backhoe components have some variations
throughout the industry.
Important:
Illustrations used in this manual may not show all
safety equipment that is recommended to ensure safe
operation of tractor and backhoe. Refer to the Safety
Precautions section of this manual for information
concerning safety. consult your dealer for further
information.
Warranty Registration
The Delivery and Warranty Registration forms must be
filled out and signed to validate your warranty
protection. The items on the form under "I hereby
Acknowledge" should be read and understood. The
terms and conditions of the warranty on this machine
are specified in the front of this manual.
Serial Number and Location
The serial number is important information about the
machine and it may be necessary to know it before
obtaining the correct replacement part. The serial
number is located on the front of valve cover. The
serial number should be recorded on the Delivery and
Registration form and also below for your reference.
The purpose of this manual is to assist you in
maintaining and operating your backhoe. Read it
carefully, it furnishes information and instructions that
will help you achieve years of dependable
performance. Some information may be general in
nature due to unknown and varying conditions.
However, through experience and these instructions,
you should be able to develop operating procedures
suitable to your particular situation.
"Right" and "Left" as used throughout this manual are
determined when the operator sit on backhoe seat.
The photos, illustrations and data used in this manual
are current at the time of printing, but due to possible
in-line production changes, your machine may vary
slightly in detail. The manufacturer reserves the right
to redesign the machine as may be necessary without
notification.
1Bucket
2Bucket Cylinder
3 Dipperstick Cylinder
4 Boom Cylinder
5Console
6Stabilizer
7Swing Cylinder
8 Boom
9Dipperstick
10 Stabilizer Cylinder
11 Swing Frame
12 Main Frame
Backhoe Serial Number Information
Date Purchased
Backhoe Serial Number
Subframe Serial Number
Dealer Name and Telephone Number
