PART ILLUSTRATIONS
GENERAL INFORMATION
Illustrations
Directional Reference
Part Order
Instructions
▶ NO.
▶ PART NO.
▶ DESCRIPTION
▶ Q'TY
▶ I.C.
▶ SERIAL or DATE
INTERCHANGEABILITY
★ Due to our policy of continuously improving products, The information contained herein is
subject to change without notice.
~4265-99999
5265-00001~
Indicates that either parts can be used.
Indicates that a new part can be used instead of an old part when you order this
part, plese order new part.
Indicates that a part has a serial number break. When you order this part, please
order a part according to the serial number of the Loader.
Indicates that either parts can not be used.
: Interchanged serial number or date.
: Indicates the interchangeability of parts due to design change.
The individual parts in their normal relationship to each other. Reference numbers are used in the
illustrations. These numbers correspond to those in the "Number" column and are followed by the quantity
required and description.
"Right hand" and "Left hand" sides are determined by seating at the operator sit on backhoe seat.
Orders must give the complete description, correct part number, the total amount required, the product
model, all the necessary serial numbers, the method of shipment and the shipping address.
: Reference numbers are assigned to parts in the figure.
:
: Quantity of part per a unit.
: Interchangeability symbol.
: Name of part and it's specification.
