GB Operating manual – multifunction measuring meter XA1000 / XP200 / XP400 • 08_2015 4
Technical data
*
Data are subject to change (e.g. new sensors for additional
measurements). As the case may be, using new sensors requires
an update of the device software.
Parameters Values
Multifunction measuring meter, model XA1000 XP200 XP400
Sensors
*
Temperature / humidity
(digital sensor)
Temperature / humidity
(digital sensor)
-
Air flow / temperature (digi-
tal sensor)
-
Air flow / temperature
(digital sensor)
Air pressure (integrated air
pressure sensor)
Air pressure (integrated air
pressure sensor)
Air pressure (integrated air
pressure sensor)
CO
2
sensor
(digital sensor)
--
Integrated air pressure sensor
Air pressure measuring range 800 to 1100 mbar (complete accuracy)
Air pressure accuracy at 25 °C, 1013.25 mbar max. ± 0.5 mbar
Air pressure long term stability type -1 mbar/year
Air pressure measurement resolution 0.024 mbar
Operating range
Operating temperature 0 °C to +50 °C
Relative air humidity
<90% or <20g/m
3
(non-condensing)
Height above sea level (NN) max. 4000 m
Storage
Relative air humidity < 90% (non-condensing)
Ambient temperature -20 °C to +60 °C
Energy
Battery 4 x Alkaline LR6 AA, 1.5 V
Optional power supply 5 V USB
Power consumption, active approx. 400 mW
Battery lifespan, passive approx. 1 year
Battery lifespan, active at least 24 h
Sensor supply 5.5 V ±10 % DC, max. 200 mA
Further information
Measured value storage
for approx. 200 measuring projects consisting of up to 3 x 3600 (=10,800) measuring
points, that is a total of 200 x 10,800 = 2,160,000 measuring points
Dimensions (L x W x H) approx. 170 x 62 x 34 mm
Weight approx. 205 g
Real time clock with calender programmed to 2099
