Chapter 4 Instruction for installation
4.1 Product connection diagram
Microphone
Amplifier
Line/MIC device Audio In
Display
(Program)
Display
(MultiView)
Router
HDMI output
LAN
Power Supply
Power Cord
HDMI Source Input
Digital Presenter
Computer
IP
Camera
Audio Output
Speaker
External
Keyboard/Mouse
Environment
Control
Equipment
USB Control
RS-232/RS-485
Control
