M3 Mobile SM15W User Manual

47
5.2 SM15N Device Specifications
Physical Features
Size
(W x L x H)
mm/inch
76.4 x 154.8 x 21.6 mm
3.00 x 6.09 x 0.85 inch
Weight
280 g / 11.8 oz (Including battery)
Screen
5.0" HD TFT LCD
Battery
Li-ion, 3.8 V 4,100 mAh
Li-ion, 3.8 V 6,150 mAh
Performance
Processor
CPU
2.0 GHz Octa-core processor
OS
Android 7.1 (8.x is scheduled)
Memory
RAM 2 GB
ROM 16 GB
Card Slot
Micro SD (Up to 128 GB)
Interface
Micro USB via Snap on
User Environment
Temperature
Use Temperature
-20 to 60℃
Storage Temperature
-30 to 80 ℃
Humidity
95% Non-condense
Tumble Test
1,000 1.6 ft./0.5M tumbles
(2,000 drops - Bumper case
mounted)
500 1.6 ft./1M tumbles
(1,000 drops - Bumper case not
mounted)
Drop Test
1.8 M / 6.0 ft. (Bumper case
mounted)
1.2 M / 3.9 ft. (Bumper case not
mounted)
IP rate
IP65
Wireless Communication Specification
WWAN
GSM: 850/900/1800MHz
Max E.I.R.Power : 32.3/29.2dBm
WCDMA : 850/900/2100MHz
Max E.I.R.Power : 22.14/22.24dBm
LTE : FDD B1, B3, B5, B7, B8, B20
Max E.I.R.Power:
22.24/23.29/22.19/23.62/23.12dBm
Wireless LAN
IEEE 802.11 a/b/g/n/ac
※ lndoor use only in 5150-5350MHz band
2.4 GHz Max E.I.R.Power : 17.66dBm
5 GhZ Max E.I.R.Power : 10.86dBm
Security
WEP, WPA, WPA2, TKIP, AES, EAP-
FAST, EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP- TLS, PEAP-MSCHAPv2, LEAP,
CCXv4
Bluetooth
Bluetooth Class II 4.1 LE
Max E.I.,R.Power :8.837dBm
NFC
ISO 1443 A/B, ISO 15693, Mifare, P2P
Max Power: -13.75dBuA/m
GPS
A-GPS, GLONASS, Beidou
General Options
Scanner
1D / 2D
Camera
Rear: 13 M pixels auto-focus (AF)
Keypad
Four physical buttons on the lower
section
