8.33 Instrument Cluster Gauges
The instrument cluster comprises of the tachometer, speedometer, trip meter (A &
B), SET button, MODE button, odometer, fuel gauge, coolant temperature gauge,
warning lamps and telltale indicators.
All the gauges have pre-check (All the gauges will show full deflection and will
come back to zero). In case of signal missing below mentioned behavior would
be shown by the cluster. In such a case please contact the dealer.
State Pre-check
Signal Invalid No Signal
Engine High Temperature
Yes ON OFF
Engine Temperature Gauge
Yes Max OFF
Vehicle Speed
Yes Max Max
Engine Speed
Yes Max Max
Odometer Reading
Yes
Odometer, Trip A, Trip B retains previous
value
8.33.1 Tachometer (if equipped)
The tachometer indicates the real time engine speed in thousands of RPM
(revolutions per minute). Each division is 500 RPM. Maintain steady engine speed
below 3000 RPM and do not accelerate or decelerate abruptly.
W12H41
W12H42
FEATURES AND CONTROL
