Mahindra 2014 Scorpio S10 User Manual

8-10
© Copyright Mahindra & Mahindra Ltd. 082014
• Sharp turn taken
8.20 Fog Lamps (if equipped)
Fog lamps are to be used along with the head lamp low beam, to improve the vision
during foggy and misty conditions.
Fog Lamps OFF
20
40
60
80
k
m
/h
10
0
120
140
160
1
8
0
W12H21
Align the inner rotary switch on the lighting control stalk to the fog lamp off ‘O’ on the
inner fixed stalk as shown to switch OFF the fog lamps.
Front Fog Lamps ON
To switch ON the front fog lamps, switch ON the ignition and the parking lamps. Turn
the inner rotary switch on the lighting control stalk to align to the fog lamp symbol on
the inner fixed stalk as shown.
The front fog lamp indicator in the instrument cluster indicates the operation status.
20
40
60
80
k
m
/h
10
0
120
140
160
1
8
0
W12H22
Fog lamps will turn ON only if the parking lamp is ON.
8.21 Puddle Lamps (if equipped)
W12H23
The puddle lamps are provided at the bottom of the front doors. They are switched
ON automatically when either of the front doors are opened. This illuminates the
ground below the respective door thereby assisting in a safe entry and exit.
FEATURES AND CONTROL
