Mahindra 2014 Scorpio S10 User Manual

7-4
© Copyright Mahindra & Mahindra Ltd. 082014
2680
4430
19
75
Lock
Un-lock
W12G07
In case the back door is open when the central locking is activated, the back
door will not be locked even if it is closed later.
If any other door is open when central locking is activated, the open door/doors
will not be locked when they are closed.
7.2.2 Central Locking/Unlocking All Doors from Inside
W12G06
A
B
W12G18
W12G20
A
B
A Lock B Unlock
Press the driver door lock tab down (A) to lock or pull out the lock tab (B) to unlock all
doors simultaneously.
7.2.3 Child Safety Rear Door Lock
2680
4430
197
5
W12G09
Your vehicle is equipped with left and right side child safety rear door locks. When
the lock mechanism is engaged, the rear door(s) cannot be opened from the inside.
The door(s) can only be opened from the outside.
LOCKS AND KEYS
