13
Only for model DUR183L
1
014165
When the cap is not in use, hang it on the hook.
Detachment
1
014157
The buckle is provided with a means of quick release.
Simply squeeze the sides and the buckle to release the
tool.
WARNING:
• Be extremely careful to maintain control of the
tool at all times. Do not allow the tool to be
deflected toward you or anyone in the work
vicinity. Failure to keep control of the tool could
result in serious injury to the bystander and the
operator.
Adjustment of the hanger position and shoulder
harness
1
014164
To change the hanger position, loosen the hex bolt on
the hanger with the supplied wrench. Then move the
hanger.
After adjusting the hanger position, tighten the hex bolt
with the wrench securely.
MAINTENANCE
WARNING:
• Always be sure that the tool is switched off
and battery cartridge is removed before
attempting to perform inspection or
maintenance on the tool. Failure to switch off
and remove the battery cartridge may result in
serious personal injury from accidental start-up.
NOTICE:
Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.
Replacing the nylon cord
WARNING:
• Make sure that the cover of the nylon cutting
head is secured to the housing properly as
described below. Failure to properly secure the
cover may cause the nylon cutting head to fly
apart resulting in serious personal injury.
013822
Take off cover from housing, pressing two latches which
are slotted section oppositely on side of housing.
1
013823
Cut a nylon line in 3-6 m. Fold the cutting line in two
halves, leave one of half longer 80-100 mm than
another.
1. 80-100 mm
1. Hex bolt
1. Buckle
1. Cap
