CAUTION: Repair the machine in accordance with “Instruction manual” or “Safety instructions”.
[2] HANDLING OF GASKET
Repair
P 2/ 18
[1] NECESSARY REPAIRING TOOLS
DescriptionCode No. Use for
Once Gasket is removed:
(1) Clean up the mating surface where the gasket was installed to maintain its sealing performance.
(2) Replace it with a new one.
Retaining ring pliers ST-2 for External ring1R004
press-fitting Spindle complete with Ball bearing 609ZZ and
Retaining ring S-9 into Pipe holder
Bearing setting pipe 23-15.21R029
press-fitting Spiral bevel gear 12 with two Ball bearing 6000ZZ
into Gear housing complete
Bearing setting pipe 25-17.21R030
removing/ installing Retaining rings S-12 and S-24
Retaining ring pliers ST-2N1R003 removing Spiral bevel gear 9
Retaining ring pliers RT-2N for Internal ring1R005 removing/ installing Retaining ring R-22
removing Ball bearing 6000DDU from Cutter shaft completeBearing setting plate 10.21R033
removing Ball bearingsGear extractor (Large)1R045
Air density tester1R127 diagnosing Carburetor
Drill chuck extractor1R139
removing Cam A from Spiral bevel gear 9
Ring 221R217
Round bar for arbor 20-1001R247 removing Spindle complete with Ball bearing 609ZZ and
Retaining ring S-9 from Pipe holder
Round bar for arbor 7-1001R236 removing Spiral bevel gear 12 from Gear housing complete
Bearing extractor (small)1R269 removing Ball bearings
Round bar for arbor 6-501R286 removing Clutch drum from Clutch case
Round bar for arbor 6-501R280 removing Cam A from Spiral bevel gear 9
Retaining ring S and R pliers1R291 removing/ installing Retaining rings
Flywheel puller1R364 removing Flywheel
Feeler gauge set1R366 adjusting Ignition coil, Spark plug
Wrench 4 (Standard equipment)783223-2
782233-6
removing/ installing M5x6 Hex socket hex bolt
Box driver 10-16 (Standard equipment) removing/ installing M6-10 Hex lock nut
Wire brush
---
cleaning Spark plug
