Commissioning and operation
24
Representation of monitor pages
The analog engine data provided by the MMDS is distributed on 4 monitor pages. On
each page, the current engine speed is displayed in the top line. The 1st page continues
with the most important engine data such as oil pressure, coolant pressure, charge-air
pressure and oil pressure in the gearbox. Other engine and gearbox data, as well as ex-
haust temperatures and supplementary information is shown on the subsequent pages:
Page 1 Actual value (example)
P1 Engine speed 2100 rpm
Oil pressure, engine 4,3 bar
Coolant temperature, engine 82 °C
Charge-air temperature 41 °C
Oil pressure, gearbox 19 bar
Page 2 Actual value (example)
P2 Engine speed 2100 rpm
Coolant pressure compensator
reservoir
830 mbar
Coolant pressure water pump 3,9 bar
Oil temperature, engine 103 °C
Battery voltage 27,1 V
Page 3 Actual value (example)
P3 Engine speed 2100 rpm
Intake air vacuum 30 mbar
Charging pressure 1,86 bar
Exhaust temperature T.A. 629 °C
Exhaust temperature T.B. 613 °C
Page 4 Actual value (example)
P4 Engine speed 2100 rpm
Fuel consumption 162 l/h
Engine load 79 %
The pages are scrolled using the “PAGE” key. Each time the key is pressed, the screen
moves up to the next page. After page 4, page 1 appears again.
For the display of current alarms and warnings, an alarm screen has been included. This
is called up using the “ALARMS” key. If there is no alarm, the message “no message”
appears on the screen.
A1 > no message
