Commissioning and operation
30
Tachometer CAN-Master
The VDO Ocean Link Tachometer (CAN-Bus Tachometer)
The VDO Ocean Link tachometer is a multifunctional instrument for
indicating engine data, and is intended for use in navigation of sports
ships. The tachometer shows the actual engine speed in operation,
on the analogue scale. Further values and operating aids appear in
the LC display.
The instrument has a push-button on the front side, with which all
the functions can be selected. Handling of the instrument is thus
easy and uncomplicated.
Main Functions
The main functions of the VDO Ocean Link can be called up by pressing the push-button. Each time the
button is pressed, the next measured value is displayed.
- Engine oil pressure - Charge air temperature
- Gearbox oil pressure - Charge air pressure
- Coolant temperature - % Load
- Engine oil temperature - Running time
- Exhaust gas temperature b. turbine 1 - Current fuel consumption
- Exhaust gas temperature b. turbine 2 - Battery voltage
- Exhaust gas temperature after turbine
The exhaust temperature to be displayed must be set when the display messages (Screen on / off).
LC‐Display Push button key
