11.3 Engine data
11.3.1 E3268 LE212/LE222
Engine model E3268 LE212/LE222
Design V 90
Operating Principle 4-stroke petrol/gas engine charged with mixturecooling
Number of cylinders 8
Bore 132 mm
Stroke 157 mm
Displacement 17,188 cc
Compression
E3268 LE212 12 : 1
E3268 LE222 13,6 : 1
Output if German Technical In
structions on Air Quality Control
comply with
natural-gas mode
E3268LE212 370 kW bei 1500 1/min
The output figures apply to operation with natural gas with a calorific value of 10 kWh/m
3
and a me
thane number > 80. If the calorific value is lower, the output will be reduced accordingly. Consultation
with MAN required.
Output if German Technical In
structions on Air Quality Control
comply with
biogas mode
E3268 LE222 370 kW bei 1500 1/min
The output figures apply to operation with biogas (60% CH
4
, 40% CO
2
) with a calorific value of
6 kWh/m
3
and a methane number of 140.
Firing order 1-5-7-2-6-3-4-8
Valve clearance (cold engine)
Intake 0.50 mm
Exhaust 0.60 mm
Valve timing
Intake opens 12 before TDC
Intake closes 48 after BDC
Exhaust opens 61 before TDC
Exhaust closes 11 after TDC
