MT 932 Série A
HYDRAULIC CIRCUIT
- Type of pump
. Capacity
- Lifting, tilting, telescoping, attachment circuit
. Max. rating capacity unladen
. Pressure
- Steering circuit
. Max. rating capacity unladen
. Pressure
- Filtration
. Return
. Suction
Gear pump with flow divider
43,77 cm3
105 L/mn
250 Bar
105 L/mn
140 Bar
20 µ
(Up to machine Nr : 166043)
15 µ (From machine Nr : 166044)
125 µ
CHARACTERISTICS
FRONT AND REAR TYRES
DIMENSIONS PRESSURE TYRE LOAD PRESSURE ON THE CONTACT SURFACE AREA OF THE CONTACT SURFACE
HARD GROUND LIGHT GROUND HARD GROUND LIGHT GROUND
OPTION
15,5/80-24 SGI TL 12PR 4 Bar 1650 kg 7,9 kg/cm2 2,1 kg/cm2 210 cm2 770 cm2
GOODYEAR 4550 kg 12 kg/cm2 3,4 kg/cm2 378 cm2 1340 cm2
2200 kg 8,8 kg/cm2 2,4 kg/cm2 251 cm2 920 cm2
850 kg 7,1 kg/cm2 1,8 kg/cm2 120 cm2 460 cm2
460/70 R24 IT520 TL 150A8 3,3 Bar 1650 kg 8,3 kg/cm2 2,3 kg/cm2 200 cm2 730 cm2
GOODYEAR 4550 kg 11,9 kg/cm2 3,1 kg/cm2 381 cm2 1470 cm2
2200 kg 9,4 kg/cm2 2,5 kg/cm2 233 cm2 890 cm2
850 kg 8,5 kg/cm2 2,2 kg/cm2 100 cm2 380 cm2
445/70R24 IT510 151G 4,1 Bar 1650 kg 8,5 kg/cm2 2,8 kg/cm2 195 cm2 587 cm2
GOODYEAR 4550 kg 10 kg/cm2 3,3 kg/cm2 456 cm2 1373 cm2
2200 kg 8,8 kg/cm2 2,9 kg/cm2 250 cm2 755 cm2
850 kg 7,4 kg/cm2 2,4 kg/cm2 115 cm2 350 cm2
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
STANDARD
14,9x24 T35 Stabilarge 18PR 3,4 Bar 1650 kg 5,7 kg/cm2 2 kg/cm2 290 cm2 830 cm2
DUNLOP 4550 kg 9,4 kg/cm2 3,1 kg/cm2 485 cm2 1460 cm2
2200 kg 6,5 kg/cm2 2,2 kg/cm2 340 cm2 990 cm2
850 kg 4,7 kg/cm2 1,6 kg/cm2 180 cm2 520 cm2
OPTION
400/70-20 T37 150B TL 14PR 3,25 Bar 1650 kg 7,3 kg/cm2 2,4 kg/cm2 225 cm2 700 cm2
DUNLOP 4550 kg 10,6 kg/cm2 3,3 kg/cm2 430 cm2 1370 cm2
2200 kg 7,9 kg/cm2 2,5 kg/cm2 280 cm2 870 cm2
850 kg 6,2 kg/cm2 2 kg/cm2 137 cm2 425 cm2
440/70-24 T37 147B TL 2,8 Bar 1650 kg 6,3 kg/cm2 1,8 kg/cm2 260 cm2 910 cm2
DUNLOP 4550 kg 9,4 kg/cm2 2,7 kg/cm2 485 cm2 1670 cm2
2200 kg 6,9 kg/cm2 2 kg/cm2 320 cm2 1110 cm2
850 kg 5,1 kg/cm2 1,5 kg/cm2 166 cm2 580 cm2
400/80-24 T37 153B TL 3,2 Bar 1650 kg 7,2 kg/cm2 2 kg/cm2 230 cm2 830 cm2
DUNLOP 4550 kg 10,2 kg/cm2 2,9 kg/cm2 445 cm2 1560 cm2
2200 kg 7,9 kg/cm2 2,2 kg/cm2 280 cm2 1020 cm2
850 kg 5,9 kg/cm2 1,6 kg/cm2 144 cm2 520 cm2
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
17,5LR24 XM27 TL 145A8 3,5 Bar 1650 kg 1,6 kg/cm2 kg/cm2 1030 cm2 cm2
MICHELIN 4550 kg 3,3 kg/cm2 kg/cm2 1370 cm2 cm2
2200 kg 2 kg/cm2 kg/cm2 1090 cm2 cm2
850 kg 0,9 kg/cm2 kg/cm2 930 cm2 cm2
Front unladen
Front laden
Rear unladen
Rear laden
OPTION
18-19.5 16PR I224 TL 5 Bar 1650 kg kg/cm2 kg/cm2 cm2 cm2
ALLIANCE 4550 kg kg/cm2 kg/cm2 cm2 cm2
2200 kg kg/cm2 kg/cm2 cm2 cm2
850 kg kg/cm2 kg/cm2 cm2 cm2
Front unladen
Front laden
Rear unladen
Rear laden
