Part Number STH025 11/16 221
NOTE: The pressure controls will operate normally once
the tubing is re-rounded. Tubing may not re-round 100%.
USING PINCH-OFF TOOL
LIQUID LINE FILTERDRIERS
The filter-driers used on Manitowoc ice machines are
manufactured to Manitowoc specifications.
The difference between a Manitowoc drier and an
off-the-shelf drier is in filtration. A Manitowoc drier has
dirt-retaining filtration, with fiberglass filters on both the
inlet and outlet ends. This is very important because ice
machines have a back-flushing action that takes place
during every Harvest cycle.
A Manitowoc filter-drier has high moisture and acid
removal capability.
The size of the filter-drier is important. The refrigerant
charge is critical. Using an improperly sized filter-drier
will cause the ice machine to be improperly charged with
refrigerant.
Important
Driers are covered as a warranty part. The drier must
be replaced any time the system is opened for repairs.
To Next Page
