Manitowoc Indigo ID0523W User Manual

230 Part Number STH025 11/16
I0450 SERIES
I0450A
Self-Contained Air-Cooled Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 10.2-11.9 11.1-12.9 12.1-14.1
1-2.5
80/27 11.4-13.3 12.3-14.3 13.3-15.5
90/32 12.5-14.5 13.8-16.1 14.8-17.2
100/38 13.8-16.1 15.4-17.9 16.6-19.3
110/43 16.3-18.9 17.7-20.5 19.3-22.4
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 420 390 360
80/27 380 355 330
90/32 350 320 300
100/38 320 290 270
110/43 275 255 235
1 Based on average ice slab weight of 3.40 - 3.90 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 195-255 50-25 125-185 70-90
70/21 195-255 60-25 135-190 80-110
80/27 220-275 62-28 135-195 80-110
90/32 250-320 70-31 175-195 85-115
100/38 290-370 75-33 190-215 115-140
110/43 310-380 80-33 210-250 120-170
1 Suction pressure drops gradually throughout the freeze cycle

Manitowoc Indigo ID0523W Specifications

General

Brand	Manitowoc
Model	Indigo ID0523W
Category	Ice Maker
Language	English
