Manitowoc Indigo ID0523W User Manual

Part Number STH025 11/16 261
I1406W
Self-Contained Water-Cooled Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 11.0-12.9 12.1-14.2 13.3-14.6
0.75-2.0
80/27 11.2-13.2 12.3-14.4 13.3-14.6
90/32 11.4-13.4 12.7-15.0 13.6-16.0
100/38 11.6-13.6 12.8-15.0 13.6-16.7
110/43 11.8-13.9 12.8-15.0
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 1495 1360 1200
80/27 1485 1340 1195
90/32 1390 1325 1195
100/38 1380 1275 1170
110/43 1370 1205 1140
1 Based on average ice slab weight of 10.25 - 11.50 lb.
OPERATING PRESSURES
Air Temp
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 240-250 40-24 155-185 75-95
70/21 240-250 40-26 165-185 75-95
80/27 240-250 50-27 165-185 75-95
90/32 245-255 50-27 185-205 85-105
100/38 245-260 54-28 205-225 95-120
110/43 245-265 60-29 225-255 105-130
1 Suction pressure drops gradually throughout the freeze cycle
2 Water regulating valve set to maintain 230 psig
3 Condenser Water Usage = 154 gal/100 lb ice @ 90°/70°F
