Manitowoc URF0140A Technician's Handbook

220 Part Number 000014797 Rev02 05/18

NOTE: These characteristics may vary depending on
operating conditions.
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser

Freeze Time Harvest
Time

  
70/21 14.6-16.5 17.6-19.9 20.3-23.0
1.0 - 2.5
80/27 15.5-17.5 18.9-21.3 22.0-24.9
90/32 17.6-19.9 22.0-24.9 26.3-29.7
100/38 20.3-23.0 23.9-27.1 29.0-32.8
Times in minutes

Air Temp.
Entering


  
70/21 95 80 70
80/27 90 75 65
90/32 80 65 55
100/38 70 60 50
Based on average ice slab weight of 1.0 – 1.3 lb (400 - 600 g).
Operating Temperatures

Air Temp.
Entering
Condenser

Freeze Cycle Harvest Cycle
Discharge
Line

Suction
Line

Discharge
Line

Suction
Line

50
10
150-165
66-74
67-50
19-10
155-190
68-88
50-60
10-16
70
21
155-185
68-85
67-50
19-10
160-190
71-88
50-60
10-16
80
27
170-190
78-88
71-58
22-14
175-190
79-88
52-65
11-18
90
32
180-205
82-96
75-65
24-18
185-210
85-99
55-75
13-24
100
38
190-215
88-102
85-70
29-21
195-220
91-104
60-75
16-24
