186 Part Number 000014797 Rev02 05/18

TOUCH PAD





Function

User interface to select ice making, delay start or cleaning

cycle and provides feedback on ice machine operation.

Check For Normal Operation

Action Normal Function

Press and hold the control

board test button for 3 seconds

All Touch Pad lights turn on

Press test button All Touch Pad lights turn off

Press power button Power light turns on

With power light energized

press the delay button 4 times

Cycles through 4 hour delay,

12 hour delay, 24 hour delay

and off

Press and hold the power

button for 3 seconds

Power light turns off

Press and hold the clean button

for 3 seconds

Clean light turns on

Press and hold the clean button

for 3 seconds

Clean light turns off

If any switches do not operate correctly, disconnect main power

to the ice machine to reset the control board and perform a

second test. If the second test doesn’t show normal function,

perform the Ohm test to verify the issue is not a wiring or control

board issue.
