Part Number 000014797 Rev02 05/18 53
Step 5 Wait until the clean cycle is complete
(approximately 22 minutes) then place the toggle switch in
the Off position and disconnect power and water supplies
to the ice machine.
n
Warning
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
Step 6 Remove parts for cleaning.
A. Remove Two Thumbscrews and Water Pump
Cover.
B. Remove the Vinyl Hose Connecting the Water
Pump and Water Distribution Tube.
C. Remove Water Pump
• Disconnect the water pump power cord.
• Loosen the screws securing the pump mounting
bracket to the bulkhead.
• Lift the pump and bracket assembly off the mounting
screws.
To Next Page
