HEATER FUNCTIONING DIAGRAM
ELECTRIC CONTROL PANEL
FLUE CONNECTIONS DIAGRAM
REGULATION OF ELECTRODES
1 Combustion chamber
2 Anti-wind flue connection
3 Burner
4 Nozzle
5 Fuel circuit
6 Fuel pump
7 Electric fuel valve
8 Motor
9Fan
10 Cable winding bracket
11 Fuel filter
12 Fuel tank
13 Control panel
1 Reset button
2 Identification label
3 Main switch
4 Socket for ambient thermostat
5Power cable
6Power indicator
HEATER FUNCTIONING DIAGRAM
1 2 3 6 8 9
12
13
11
4
5 7
10
ELECTRIC CONTROL PANEL
123 546
FLUE CONNECTIONS DIAGRAM REGULATION OF ELECTRODES
2-3 mm
214356
Pipe Ø 150 mm
