DIODE AND CONTINUITY TEST
OPERATING INSTRUCTIONS
DATA HOLD MODE
Press the "H" button to hold the present reading on the display, " "
will appear on the display as an indication.
To exit Data Hold mode, press the button again. " " disappears.
RANGE DESCRIPTION TEST CURRENT
The approx. forward voltage drop
of the diode will be displayed.
The built-in buzzer will sound if
the resistance is less than
about 20 Ω.
The buzzer may or may not
sound if the resistance is
between 20 Ω and 100 Ω.
The buzzer will not sound if the
resistance is more than 100 Ω.
Open Circuit Voltage:
about 2.8 V
Test Current:
about 1 mA
Open Circuit Voltage:
about 2.8 V
model no. 052-0055-6 | contact us 1-800-689-9928
13
